Automatic Powder Coating Plant

Automatic Powder Coating Plant
Automatic Powder Coating Plant
Product Code : 01
Brand Name : SSA
Product Specifications
  • Type
  • Manual Conveyorised
  • Material
  • MS / Al
  • Automatic Grade
  • Semi-Automatic
  • Drive Type
  • Electric
  • Color
  • Any Color
  • Warranty
  • 1 year
Trade Information
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Unit/Units
  • Payment Terms
  • Cheque, Others, Cash in Advance (CID), Cash Against Delivery (CAD)
  • Supply Ability
  • 20 Plants Per Year
  • Delivery Time
  • 3-4
  • Main Export Market(s)
  • Asia, Middle East
  • Main Domestic Market
  • All India
  • Certifications
  • ISO Certificate, CE Certificate
Product Description

Powder Coating Plants which we manufacture and provide services for encompass type and design of Curing Oven, Fuel Choice, Booth Type, Coating and Recovery System Selection and Optimal Layout. These are known for their optimum performance and controlled emissions & waste disposal compared to its conventional counterparts. Powdered polymer paint, electrostatically charged with a help of a gun is applied on the metal surface which is further cured in a curing oven to obtain a paint skin with a premium finish and durability. Powder Coating Plants are available in batch type and conveyorised type.

More Product Details:

It offers significant performance with lower costs and controlled emissions & waste disposal compared to its conventional counterparts. Powdered polymer paint, electrostatically charged with a help of a gun is applied on the metal surface which is further cured in a curing oven to obtain a paint skin with a superior finish and durability.

To set up a Powder Coating Plant various parameters must be kept in mind such as the sizes and shapes of the components, coating quality and thickness of paint required, the production speed, space available and many more. Our firm specialises in surface coatings and well help you to provide with a state of the art Coating Plant, well worthy of your investment.

There are basically two types of plants available in the industry:

  • Batch Type

  • Conveyorised Type

Batch Plant:

A batch type plant is a customised solution for low production volume and low initial investment and is the optimal solution for a batch type of production. Besides the pre-treatment line, batch plant consists of a coating booth with its recovery system, applicators (guns), curing oven and the material handling system (Trolley or Manual Conveyor).

Conveyor Plant:

Conveyorised powder coating plants are customised for powder coating of any size of components and high production volume. The conveyorised plants give better and uniform coating qualities with better process controls. These plants can be integrated with automated painting guns or reciprocators.

Construction:

A powder coating plant mainly comprises of the following:

Pre Treatment Process Line:

This is the foremost process of powder coating and also called part preparation in which all the unwanted particles are removed. This contains a series of tanks or spray booths filled with chemicals and water.

Painting Booth:

These types of booths consist of a rectangular chamber, powder recovery system, motor & bin. Each part of the booth is customised for economic, production and space optimality.

Curing Oven:

An insulated box shaped (Oven) structure made up of GI sheet and glass wool to provide with an insulated environment inside the oven. As the temperatures inside the oven are generally around 200 Degrees to bake the powdered polymer paint.

Material Handling System:

A batch plant material handling system comprises of over-head track and loose trolley or ground trolley. Track and trolley is used for lighter articles. For heavy articles load bar is suitable. Whereas for conveyorised plant a overhead conveyor is once and for all solution for the material handling system requirement.

Accessories
:

To enhance the production, quality and the life of the plant and further reduce any environmental pollution and overhead costs for running the plant, there are many custom made solutions available.
